LARCH WOOD FACADES WITH THREE DIMENSIONAL PROFILES

The three-dimensional BIO3D profiles in terms of design offer endless possibilities for a unique look that provides for a precise and fast installation. All the profiles can be combined with each other in a complete system which, thanks to the particular clip fixing substructure, allows an invisible assembly of the boards with an elegant design in which all components are designed to fit perfectly together.



The Siberian larch of the BIO3D profiles grows very slowly in the Nordic woods, thus becoming very robust and dimensionally stable. These solid wood profiles, even without treatments, are ideal for a long-lasting, original and personalized facade. The three-dimensional profiles differ in thickness and width, but they adapt perfectly when mixed together. This creates three-dimensional surfaces with a homogeneous and regular or lively and casual appearance.



BIO3D larch profiles are quick to assemble with male-female connection and become more resistant if installed vertically. The fixing points are in fact well protected by the profiling and the rainwater is drained downwards in an optimal way and the facade is immediately dry. You can use the three-dimensional variations of the BIO3D profiles for an even more creative architecture. By playing with the different thicknesses of the profiles you can obtain reliefs that will be emphasized even more by the play of light and shadows of the sun and clouds.

ProfileDimensions (mm) Species Surface / finish Length (m) Pieces per pack code
BIO3D-1N- LARCH 27x144 Siberian larch Flat - natural 3.00 / 4.00 843567193
BIO3D-1N- LARCH 27x144 Siberian larch Piana - silver gray colored 3.00 / 4.00 843567262
BIO3D-3N- LARCH 27x144 Siberian larch Flat - natural 3.00 / 4.00 843567216
BIO3D-3N- LARCH 27x144 Siberian larch Piana - silver gray colored 3.00 / 4.00 843567216
BIO3D-1N- LARCH 44x144 Siberian larch Flat - natural 3.00 / 4.00 843567239
BIO3D-1N- LARCH 44x144 Siberian larch Piana - silver gray colored 3.00 / 4.00 843567308
